VW T5 & T6 Chassis Cab Full Air Suspension Kit

Product Code:DR.04.013528

Specifications

Cross Reference Kit Number W21-760-3528
European / US Vehicle Europe
Years 2004 - Current
Average Installation Time 5 -6 hours
Air Spring Style Double Convolute
Air Spring DR.07.016988
Air Compressor DR.12.011201
Operating Pressure 0 - 12 bar
Control System IntelliRide ECAS
Ride Height (front & rear) 450 mm
Lowered Height (front) 410 mm
Lowered Height (rear) 360 mm
Raised Height (front & rear) 480mm
Kit Weight 52 Kg

Applications

Volkswagen T5 04-15 (Chassis Cab)
Volkswagen T6 16-Current (Chassis Cab)

Special Notes

Suitable for 3.2 T Gross Vehicle Weight VW T5 & T6 vehicles with a front axle load rating of 1710 Kg.

For 2.8 T Grosse Vehicle weight Light Duty applications with front axle load rating up to 1540 Kg, see DR.04.013527.

Downloads

Related Products

DR.04.013527

VW T5 & T6 Chassis Cab Full Air Suspension Kit

4 Corner Full-Air kit with IntelliRide Height Control



Click thumbnail to view detailed image.



4 Corner Full Air Suspension Kit.

Requires the removal of the original vehicle coil springs.

Full IntelliRide ECAS control system with lowering facility.

Available Heights - 3

  • Ride Height (standard)
  • Lowered Height (standard)
  • Upper / Raised Height (optional)

The standard VW T5 & T6 vehicles are easily converted to Full Air Suspension using the Drive-Rite suspension system.

INCREASED SAFETY

GREATER SECURITY

MORE COMFORT

MAINTAIN CORRECT VEHICLE HEIGHT

Improve steering control and braking effectiveness, level headlight beams and reduce tyre wear.

LEVEL OFF-CENTRE LOADS

Individual inflation valves allow for adjustment side-to-side.

NO MORE SPRING SAG

Keep leaf springs from permanent sagging under repeated or constant load.

SAFER LOAD CARRYING

Protective air cushion softens contact between the axle and frame.

IMPROVED STEERING & HANDLING

Absorbing road shock providing ideal ride conditions for passengers and load.

LOWERING FACILITY

Lowering facility for easy loading/ unloading of passengers and goods

EUROPEAN DESIGNED, MANUFACTURED, TESTED & APPROVED

All our kits are designed, manufactured to the highest standard

SUITABLE APPLICATIONS:
  • Ambulances
  • Minibuses
  • Firebrigades
  • Breakdown Vehicles
  • Disabled TransportTransportation of Delicate Loads
  • Specialist Vehicles
  • Motor Caravans
