267C-1.5 Air Spring

Product Code:DR.07.016784

Specifications

Part Number DR.07.016784
Air Spring Style Style 267C-1.5
Cross Reference Number W21-760-6784
Assembly Weight 1.7 kg
Force to collapse to min height (@ 0 BAR) 190 N
Minimum Height 76 mm
Maximum Stroke 112 mm
Maximum Usable Height 188 mm
Thread - Mounting Fittings Imperial
Thread - Air Feed Imperial
Loading Capacity @ 3 Bar 2.71 kN
Loading Capacity @ 5 Bar 4.83 kN
Loading Capacity @ 7 Bar 7 kN
Natural Frequency Range @ 7 BAR 2.08 Hz
Maximum Diameter @ 7 BAR 163 mm
Operating Temperature -37°C to 57°C
