Light Duty Compressor Control Kit - Dual

Product Code:DR.11.016112

Specifications

Compressor Light Duty
Compressor Part # DR.12.011260
Operating Pressure 0 - 7 Bar
Operating Voltage 12 V
Gauge Type Dual
Gauge Part #
Low Pressure Sensor Yes
Air Line Tubing 1/4"
Kit Weight 2 Kg
Average Installation Time 1 Hour



Downloads

Related Products

DR.11.016110

Light Duty Compressor Control Kit - Single

Light Duty Compressor and Single Gauge Accessory Kit



Click thumbnail to view detailed image.

Light Duty Compressor and Dual Gauge Accessory Kit

Dual gauge operation inflates the rear air springs independently.

As an added safety measure, the Drive-Rite DR.11.016112 control system automatically senses low air spring pressure and immediately activates to maintain a safe pressure level.

The Drive-Rite DR.11.016112 Air Compressor System is the quick and convenient way to inflate and deflate your vehicle’s air springs while on the go - from the cab of your vehicle. The last place you probably want to drive your loaded vehicle to is a service station to fill up your air springs. With a Drive-Rite Dual air compressor system, you can forget about having to search out an air compressor to inflate your air springs ever again!

With the touch of a button, control the pressure in your air springs . This is extremely convenient for changes in load or road conditions.

The gauge mounts in your vehicle’s cab and operates regardless of whether you are parked or on the road. The user-friendly gauge has easy-to-use inflate and deflate buttons to let you quickly inflate or deflate your vehicle’s air spring pressure.

The DR.11.016112 Air Compressor System provides a separate path airflow to each of your vehicle’s air springs. This means your left and right air springs inflate and deflate independently. This is most useful to level off-centre loads. For single control of the air springs, see our Single Air Compressor System part number DR.11.016110.

This system includes a standard duty compressor, wiring harness, air lines, dual gauge and 2 low pressure sensors. A standard duty compressor will work well for most customers who use their system on an intermittent basis. The compressor mounts easily to your vehicle's frame and attaches to an air line that runs to your air springs.

You can install the system yourself in a few hours with the help of a fully illustrated easy-to-follow installation manual.
