Air Compressor - Super Heavy Duty
Product Code:DR.12.019285
Specifications
| Compressor Type | Firestone |
| Part # | DR.12.019285 |
| Integrated Dryer | No |
| Integrated Quick Release | No |
Electrical Data
| Operating Voltage Range | 9 - 16 V DC |
| Max. AMP Draw | 16 Amps |
| Duty Cycle | 30% |
| Temperature Range | -40 degC to 70 degC |
Pneumatic Data
| Pressure Control | 150psi |
| Volume Fill Time (RT) | 0-145psi (10 bar) in 281 sec for 2.5 gallon |
Other Data
| Mounting Position | Multi-axis |
| Weight | 1.79 kg (6.95lbs) |
| Flow Data | See Spec Image |
| Tube Connection | 1/4" tube |
| Standard Filter Kit |
DR.12.019129 |
Click thumbnail to view detailed image.
Super Heavy Duty Compressor
The Super Heavy Duty Firestone compressors are direct drive compressors (no oil or belts), so the compressors can be mounted in any position.
The system offers a dependable, lasting service for moderate use applications.
