4 Corner Heavy Duty IntelliRide Control Kit

Product Code:DR.30.010404

Specifications

Compressor AMK x 2
ECU 4C ECU
Height Sensors 4
Valve Manifold 5/2x2
HandHeld Controller 4C Handheld
Air Reservoir        11.35 Litres (3 Gallons)
No. of Preset Heights Available 3
Manual Control Available Yes
Horizon Levelling N/A
Handheld Calibration Yes
Kit Weight 26 Kg



Downloads

Related Products

DR.12.011201

12V AMK Compressor

12V AMK Compressor

DR.30.010604

4 Corner HD IntelliRide Control Kit - With Horizon Leveling

4 Corner kit with 2 Compressor and includes Horizon Levelling

DR.32.014100

4 Corner ECU - Programmed without a Horizon Levelling Sensor

Pre-programmed 4 Corner ECU for systems without a Horizon Leveling Sensor



Click thumbnail to view detailed image.



IntelliRide ECAS Control

  • Generic Control Kits - suits all vehicle types and applications
  • Variable ride height - for access, off-road and high-speed driving
  • Load-levelling
  • Near-constant ride frequency - load independent
  • Variable spring rate with optional driver adjustment
  • Optimized geometry (Drive-line angles)
  • Improved Ride Quality
  • Improved head lamp aim
  • Easy Installation
  • Calibrate through Handheld
  • Windows based, user friendly calibration and diagnostic tools available on request

IntelliRide is a fully automatic, Electronically Controlled Air Suspension (ECAS) System. When fitted the system provides comfort while maintaining a programmed ride height irrespective of the load. Multiple vehicle heights are available at the push of a button. The IntelliRide system has automatic
load levelling at each height.

The IntelliRide system continuously monitors inputs and component performance as a means of increasing safety and durability. The system recognizes and responds accordingly to potholes, cross-articulation and extended turns. This intelligence prevents unnecessary activity and air consumption. The system even recognizes unachievable heights, assisting in the prevention of possible damage above or below the vehicle.
